AIエージェントとシステムをつなぐMCP入門（認証/認可編）

app.use(
  mcpAuthMetadataRouter({
    oauthMetadata,
    resourceServerUrl: mcpServerUrl,
    scopesSupported: [REQUIRED_SCOPE],
    resourceName: "MCP Auth Streamable HTTP",
  }),
);

{
  "resource": "http://localhost:3000/mcp",
  "authorization_servers": ["http://localhost:8081/realms/mcp-demo"],
  "scopes_supported": ["mcp:tools"],
  "resource_name": "MCP Auth Streamable HTTP"
}

const authMiddleware = requireBearerAuth({
  // ※1
  verifier: tokenVerifier,
  // ※2
  requiredScopes: [REQUIRED_SCOPE],
  resourceMetadataUrl: getOAuthProtectedResourceMetadataUrl(mcpServerUrl),
});

//omit

app.post(MCP_PATH, authMiddleware, async (req, res) => {
  const server = createServer(); // authMiddlewareでエラーが発生した場合、ここは実行されません
  // omit

export function createTokenVerifier(mcpServerUrl: URL): OAuthTokenVerifier {
  return {
    verifyAccessToken: async (token) => {
      // Keycloakのイントロスペクションでトークン検証　※1
      const params = new URLSearchParams({token, client_id: OAUTH_CLIENT_ID});
      if (OAUTH_CLIENT_SECRET) params.set("client_secret", OAUTH_CLIENT_SECRET);
      const response = await fetch(KEYCLOAK_INTROSPECTION_ENDPOINT, {
        method: "POST",
        headers: { "Content-Type": "application/x-www-form-urlencoded" },
        body: params.toString(),
      });

      // 200 以外を返した場合　※2
      if (!response.ok) {
        const text = await response.text().catch(() => "");
        throw new OAuthError(OAuthErrorCode.InvalidToken, `Invalid or expired token: ${text}`);
      }

      // omit

      // トークンが無効または期限切れの場合　※3
      if (!data.active) throw new OAuthError(OAuthErrorCode.InvalidToken, "Inactive token");

      // Audience (aud) クレームの検証
      if (OAUTH_STRICT) { // OAUTH_STRICTを有効にしている場合、検証を実行します
        // ※1
        if (!data.aud) throw new OAuthError(OAuthErrorCode.InvalidToken, "Resource indicator (aud) missing");
        const audiences = Array.isArray(data.aud) ? data.aud : [data.aud];
        const allowed = audiences.some((audience) =>
          checkResourceAllowed({ requestedResource: audience, configuredResource: mcpServerUrl }),
        );
        // ※2
        if (!allowed) throw new OAuthError(OAuthErrorCode.InvalidToken, `Expected audience compatible with ${mcpServerUrl}, got: ${audiences.join(",")}`);
      }

OAuth Authorization Failed
Policy 'Allowed Client Scopes' rejected request to client-registration service. Details: Not Permitted to use specified clientScope

Error from MCP server: StreamableHTTPError: Streamable HTTP error: Error POSTing to endpoint: {"error":"invalid_token","error_description":"Missing Authorization header"}
    at StreamableHTTPClientTransport.send (file:///xxx/node_modules/@modelcontextprotocol/sdk/dist/esm/client/streamableHttp.js:364:23)
    at process.processTicksAndRejections (node:internal/process/task_queues:104:5) {
  code: 401
}

curl -i -X POST http://localhost:3000/mcp \
  -H "Accept: application/json, text/event-stream" \
  -H "Content-Type: application/json" \
  -d '{"jsonrpc":"2.0","id":1,"method":"tools/list","params":{}}'

HTTP/1.1 401 Unauthorized
WWW-Authenticate: Bearer error="invalid_token", error_description="Missing Authorization header", scope="mcp:tools", resource_metadata="http://localhost:3000/.well-known/oauth-protected-resource/mcp"

curl -s http://localhost:3000/.well-known/oauth-protected-resource/mcp

{
  "resource":"http://localhost:3000/mcp",
  "authorization_servers":["http://localhost:8081/realms/mcp-demo"],
  "scopes_supported":["mcp:tools"],
  "resource_name":"MCP Auth Streamable HTTP"
}

curl -s -X POST http://localhost:8081/realms/mcp-demo/protocol/openid-connect/token \
-H "Content-Type: application/x-www-form-urlencoded" \
-d "grant_type=client_credentials" \
-d "client_id=mcp-demo-client" \
-d "client_secret=mcp-demo-client-secret"

{
  "access_token":"<valid_token>",
  "expires_in":300,
  "refresh_expires_in":0,
  "token_type":"Bearer",
  "not-before-policy":0,
  "scope":"mcp:tools"
}

curl -s -X POST http://localhost:3000/mcp \
  -H "Accept: application/json, text/event-stream" \
  -H "Authorization: Bearer <valid_token>" \
  -H "Content-Type: application/json" \
  -d '{"jsonrpc":"2.0","id":1,"method":"tools/list","params":{}}'

event: message
data: {"result":{"tools":[{"name":"sum_numbers","title":"sum_numbers","description":"Sum two numbers","inputSchema":{"type":"object","$schema":"https://json-schema.org/draft/2020-12/schema","properties":{"a":{"type":"number","description":"first number"},"b":{"type":"number","description":"second number"}},"required":["a","b"]},"outputSchema":{"$schema":"https://json-schema.org/draft/2020-12/schema","type":"object","properties":{"result":{"type":"number","description":"sum result"}},"required":["result"],"additionalProperties":false}},{"name":"get_server_policy","title":"get_server_policy","description":"Return simple authorization policy for demo","inputSchema":{"type":"object","properties":{}},"outputSchema":{"$schema":"https://json-schema.org/draft/2020-12/schema","type":"object","properties":{"resource":{"type":"string","description":"resource server url"},"requiredScope":{"type":"string","description":"required scope"}},"required":["resource","requiredScope"],"additionalProperties":false}}]},"jsonrpc":"2.0","id":1}

curl -i -X POST http://localhost:3000/mcp \
  -H "Accept: application/json, text/event-stream" \
  -H "Content-Type: application/json" \
  -H "Authorization: bad_format_token" \
  -d '{"jsonrpc":"2.0","id":1,"method":"tools/list","params":{}}'

HTTP/1.1 401 Unauthorized
WWW-Authenticate: Bearer error="invalid_token", error_description="Invalid Authorization header format, expected 'Bearer TOKEN'", scope="mcp:tools", resource_metadata="http://localhost:3000/.well-known/oauth-protected-resource/mcp"

{
  "error":"invalid_token",
  "error_description":"Invalid Authorization header format, expected 'Bearer TOKEN'"
}

curl -i -X POST http://localhost:3000/mcp \
  -H "Accept: application/json, text/event-stream" \
  -H "Content-Type: application/json" \
  -H "Authorization: Bearer unknown_token" \
  -d '{"jsonrpc":"2.0","id":1,"method":"tools/list","params":{}}'

HTTP/1.1 401 Unauthorized
WWW-Authenticate: Bearer error="invalid_token", error_description="Inactive token", scope="mcp:tools", resource_metadata="http://localhost:3000/.well-known/oauth-protected-resource/mcp"

{
  "error":"invalid_token",
  "error_description":"Inactive token"
}

curl -s -X POST http://localhost:8081/realms/mcp-demo/protocol/openid-connect/token \
  -H "Content-Type: application/x-www-form-urlencoded" \
  -d "grant_type=client_credentials" \
  -d "client_id=mcp-demo-no-scope-client" \
  -d "client_secret=mcp-demo-no-scope-client-secret"

{"access_token":"<valid_token>","expires_in":300,"refresh_expires_in":0,"token_type":"Bearer","not-before-policy":0,"scope":"mcp:no-scope"}

curl -i -X POST http://localhost:3000/mcp \
  -H "Accept: application/json, text/event-stream" \
  -H "Authorization: Bearer <valid_token>" \
  -H "Content-Type: application/json" \
  -d '{"jsonrpc":"2.0","id":1,"method":"tools/list","params":{}}'

HTTP/1.1 403 Forbidden
WWW-Authenticate: Bearer error="insufficient_scope", error_description="Insufficient scope", scope="mcp:tools", resource_metadata="http://localhost:3000/.well-known/oauth-protected-resource/mcp"

{"error":"insufficient_scope","error_description":"Insufficient scope"}

curl -s -X POST http://localhost:8081/realms/mcp-demo/protocol/openid-connect/token \
  -H "Content-Type: application/x-www-form-urlencoded" \
  -d "grant_type=client_credentials" \
  -d "client_id=mcp-demo-no-audience-client" \
  -d "client_secret=mcp-demo-no-audience-client-secret"
{"access_token":"<valid_token>","expires_in":300,"refresh_expires_in":0,"token_type":"Bearer","not-before-policy":0,"scope":""}

curl -i -X POST http://localhost:3000/mcp \
  -H "Accept: application/json, text/event-stream" \
  -H "Authorization: Bearer <valid_token>" \
  -H "Content-Type: application/json" \
  -d '{"jsonrpc":"2.0","id":1,"method":"tools/list","params":{}}'

HTTP/1.1 401 Unauthorized
WWW-Authenticate: Bearer error="invalid_token", error_description="Resource indicator (aud) missing", scope="mcp:tools", resource_metadata="http://localhost:3000/.well-known/oauth-protected-resource/mcp"

{"error":"invalid_token","error_description":"Resource indicator (aud) missing"}

curl -s -X POST http://localhost:8081/realms/mcp-demo/protocol/openid-connect/token \
  -H "Content-Type: application/x-www-form-urlencoded" \
  -d "grant_type=client_credentials" \
  -d "client_id=mcp-demo-diff-audience-client" \
  -d "client_secret=mcp-demo-diff-audience-client-secret"
{"access_token":"<valid_token>","expires_in":300,"refresh_expires_in":0,"token_type":"Bearer","not-before-policy":0,"scope":"mcp:diff-audience"}

curl -i -X POST http://localhost:3000/mcp \
  -H "Accept: application/json, text/event-stream" \
  -H "Authorization: Bearer <valid_token>" \
  -H "Content-Type: application/json" \
  -d '{"jsonrpc":"2.0","id":1,"method":"tools/list","params":{}}'

HTTP/1.1 401 Unauthorized
WWW-Authenticate: Bearer error="invalid_token", error_description="Expected audience compatible with http://localhost:3000/mcp, got: http://localhost:3000/mcp-diff", scope="mcp:tools", resource_metadata="http://localhost:3000/.well-known/oauth-protected-resource/mcp"

{"error":"invalid_token","error_description":"Expected audience compatible with http://localhost:3000/mcp, got: http://localhost:3000/mcp-diff"}
